1. Standard operating conditions

The standard working condition of the asphalt mixing equipment refers to the working condition when the ambient temperature is 20C, the standard atmospheric pressure, the average moisture content of the cold aggregate is 5%, the hot aggregate temperature is 160C, the cycle time is 45s, and the finished material is medium-grained.

2. Structure type

The structure types of asphalt mixing equipment are classified according to different ways and have different opinions. -Generally classified according to the following sentiments:

According to the production process, it is divided into: intermittent and continuous;

According to the transportation method, it can be divided into fixed type, removable type and mobile type.

The type of asphalt mixing plant can be combined, such as: removable intermittent type, mobile intermittent type, etc.

3. Design capacity

The design of asphalt mixing equipment mainly refers to the capacity of the mixing tank, which is mainly for the intermittent type. The capacity of intermittent asphalt plant is basically 1000kg, 2000kg, 3000kg, 4000kg.

4. Working cycle

The productivity of asphalt mixing equipment is determined by the capacity of the mixing tank and the working cycle. The working cycle refers to the time difference from the discharge of the mixing tank to the next discharge. Under standard working conditions, it is generally 45s. But for continuous, there is no duty cycle.

5. Productivity

Yield refers to the production capacity of asphalt mixing plant per hour under standard working conditions. For batch asphalt mixing plant, the production capacity of the equipment is calibrated with the rated productivity. For example: the rated productivity of the 1000 model is 120t/h; the rated productivity of the 2000 model is 160t/h; the rated production of the 3000 model

The rate is 240t/h; the rated productivity of the 4000 model is 320t/h.

6. Installed power

The installed power refers to the sum of the rated power of all electrical equipment of a set of asphalt mixing plant.

7. Fuel consumption

Fuel consumption refers to the weight of fuel consumed by the burner on the drying drum to produce 1 ton of qualified finished materials.

8. Emission index

Asphalt mixing plant has two environmental protection indicators. -Is the pollutant emission concentration, and the other is the pollutant emission blackness. According to national standards, the smoke emission concentration of asphalt mixing plant is <100mg/Ni, and the smoke emission blackness is not more than Ringerman degree I.

9. Measurement accuracy

Asphalt mixture is designed strictly according to the ratio of aggregate, asphalt, ore powder, and additives. Therefore, the control of the measurement accuracy of aggregate, asphalt, ore powder, and additives is the guarantee of the quality of the asphalt mixture. According to national standards, the measurement accuracy of asphalt mixing plant is divided into static and dynamic measurement accuracy. No matter what type of asphalt plant, the measurement accuracy should be consistent.
